Alibaba Supplier TBK 958M TBK958M TBK-958M Auto Focus Engraving Mini Portable Rear Back Door Glass Removing and Separating Laser Machine for Cell phone and mobile phone with Logo Printer

Alibaba Supplier TBK 958M TBK958M TBK-958M Auto Focus Engraving Mini Portable Rear Back Door Glass Removing and Separating Laser Machine for Cell phone and mobile phone with Logo Printer

Main Features:
*    Automatically Focus: Marking positioning is more intuitive; Realize precise positioning by projecting graphic trajectory preview
*    Automatically Lifts up and down: Recognize and automatically adjust the height according to the size of the marked item
*    Small Size, Light Weight
*    Featured high-speed galvanometer
*    Supports several times of etching,  and 2~5 times higher than ordinary galvanometer
*    Recommend to use with automatic centering fixture

Laser Parameters:
*    Laser power (Watts):     6W
*    Laser wave length:    1064nM
*    Laser marking Precision:     <0.001mm
*    Repeat laser marking precision: ≤0.001mm
*    Laser speed:    ≤10000mm/s
*    Laser marking depth:     0.015~0.5 mm
*    Max marking size:    175*175mm
*    Marked line width:    0.05~0.1mm
*    Height of the object carved by laser (mm):    85

*    Optional part-1: Fume extractor/smoke absorber, not included
*    Optional part-2: Position mold, not included
*    Optional part-3: Pressure-bonding mold, not included

Product Details:
*    Model: TBK-958M
*    AC input (Power adapter):  110-240V, 50/60Hz
*    Product Full size (mm):   365*230*420
*    Product power:    500 W
*    Net weight (kgs):    6.2
*    Gross weight (kgs):    8.0
*    Package size (cm):    40*20*50
